Details
LTC203 3 Tons Hydraulic Double Drum Road Roller
Main Features
1.Hydraulic double wheels drive,hydraulic front drum vibration and steering,with reliable performance and optimum/price ratio;
2.Both front and rear wheels have scraping and water spray unit,advanced sprinkler pump system can achieve intermittent, greatly expanded mechanical proper working condition;
3.Adopt ZN390B diesel engine,very convenient for use and maintenance;
4.Compact integral structure,small volume,capable of used for compaction on narrow site,with small investment,quick return of good economic;
Main Technical Parameters
Model | LTC203 | |
Operating mass | kg | 3300 |
Static linear load | N/cm | 136/136 |
Vibration amplitude | mm | 0.5/0.5 |
Centrifugal force | KN | 2*30 |
Vibration frequency | KZ | 50 |
Travel speed | Km/h | 0-12 |
Grade ability | % | 30 |
Steering angle | ° | ±26 |
Drum diameter | mm | 700 |
Drum width | mm | 1250 |
Wheel base | mm | 2010 |
Diesel model | ZN390B | |
Diesel power | Kw | 26.5 |
Water tank capacity | L | 200 |
Overall dimension | mm | 2760*1400*2520 |
