Details
LTP2030H 20 Tons -30 Tons Hydraulic Pneumatic Tires Road Roller
Main Features
1.With stepless speed changes LTP2030H is easy and reliable to operate;
2.Three forward speed and two backward changes.Reinforced plastic spraying box and multi-layer water filter ensure the stability of the system.
Main Technical Parameters
Model | LTP2030H | |
Operating mass(unballast/ballast) | kg | 20000/30000 |
Max.travel speed | Km/h | 10 |
Tyre quantity(front +back ) | / | 5+6 |
Min. Turning radius | mm | 8000 |
The presses width | mm | 2790 |
Grade ability | % | 30 |
wheelbase | mm | 3800 |
Overall dimension | mm | 4950*2750*3240 |
Diesel power | kw | 125 |
Diesel model | Cummins 6BTA5.9 |
