Details
LTC206 6 Tons Hydraulic Double Drum Road Roller
Main Features
1.Equipped with a National lV emission diesel engine, it has high power, low fuel consumption, and is energy-saving and environmentally friendly.
2.Front and rear wheel hydraulic drive, using plunger pump and high torque motor, continuously variable speed, strong slope ability.
3.The front and rear steel wheels vibrate, and the unique lubrication structure of the wheel body provides sufficient lubrication to the vibrating bearings during rotation and vibration.greatly improving the service life of the bearings.
4.Electronic control for vibration initiation. enabling separate vibration of the front and rear wheels. Hydraulic steering, articulated frame, easy and flexible operation.
5.Steel wheels are equipped with electrically controlled drinks to meet the construction needs of users in different periods and occasions.
6.Hydraulic walking brake, safe and reliable.Open the hood wide, and maintenance and repair tips are within reach.
Main technical parameters
MODEL | LTC206 | |
Operating mass | kg | 5700 |
Static linear load | N/cm | 200/180 |
Travel speed | Km/h | 0-12 |
Turning radius | mm | 5400 |
Ground clearance | mm | 300 |
Track width | mm | 2460 |
Compaction width | mm | 1500 |
Drum diameter | mm | 900 |
Steel wheel thickness | mm | 20 |
Rear tire model | / | |
Number of rear tire | / | |
Grade ability | % | 30 |
Steering angle | 。 | 30 |
Vibration frequency(Front/rear) | Hz | 55/50 |
Vibration amplitude | mm | 0.6 |
Centrifugal force | kN | 60*2 |
Sprinkle model | Electric sprinkler | |
Hydraulic tank capacity | L | 110 |
Fuel tank capacity | L | 110 |
Water tank capacity | L | 200 |
Overall dimension | mm | 3380*1650*2750 |
Diesel model | V20-50C41 | |
Diesel power | kW | 36.8 |
Diesel speed | r/min | 2400 |
