Details
LT216B 16 Tons Single Drum Mechanical Road Roller
Main Features
1.Mechanical travel drive,double amplitude,hydraulic vibration and steering with optimal function/price ratio and reliable performance;
2.Two sets of brake devices, a hand brake and foot pedal brake,assure the machine’s safety and dependability;
3.Spacious and comfortable cab mounted on top quality rubber damping elements;
4.World advanced technology is adopted for the hydraulic vibration technology,high in reliability ,simple and convenient in maintenance ,and low in lost;
Main Technical Parameters
Model | LT216B | |
Operating mass | kg | 16000 |
Static linear load | N/cm | 380 |
Vibration frequency | HZ | 30 |
Vibration amplitude | mm | 1.8/0.9 |
Centrifugal force | KN | 320/180 |
Travel speed | Km/h | 2.0--10.5 |
Grade ability | % | 30 |
Ground clearance | mm | 432 |
Turning radius | mm | 7000 |
Drum diameter | mm | 1570 |
Drum width | mm | 2100 |
Drum rim thickness | mm | 24 |
wheelbase | mm | 3265 |
Overall dimension | mm | 6062*2280*3050 |
Diesel model | Cummins6BT5.9 | |
Diesel power | kw | 112 |
Diesel speed | R/min | 2000 |
Fuel tank capacity | L | 220 |
