LT212B 12 Tons Mechanical Single Drum Road Roller
Main Features
1.Mechanical travel drive, double amplitude, hydraulic vibration and steering with optimal function/price ratio and reliable performance.
2.Reliable cummins6BT5.9 diesel engine for convenient operation and maintenance.
3.Two sets of brake devices, a hand brake and foot pedal brake, assure the machine's safety and dependability.
4.Spacious and comfortable cab mounted on top quality rubber damping elements.
5.World advanced technology is adopted for the hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost.
6.Equipped with padfoot or removal padfoot as option.
Main Technical Parameters
Model | LT212B | |
Operating mass | kg | 12000 |
Static linear load | N/cm | 280 |
Vibration frequency | HZ | 30 |
Vibration amplitude | mm | 1.6/0.8 |
Centrifugal force | KN | 260/160 |
Travel speed | Km/h | 2.0--10.5 |
Grade ability | % | 30 |
Ground clearance | mm | 360 |
Turning radius | mm | 7000 |
Drum diameter | mm | 1400 |
Drum width | mm | 2100 |
Drum rim thickness | mm | 24 |
wheelbase | mm | 3060 |
Overall dimension | mm | 5650*2280*3000 |
Diesel model | Cummins6BT5.9 | |
Diesel power | kw | 97Kw |
Diesel speed | R/min | 2000 |
Fuel tank capacity | L | 220 |
