Key Specifications

• Operating Weight: 1,600 kg
• Dimensions (L×W×H): 2,240 × 1,085 × 2,260 mm
• Drum Width: 1,000 mm; Drum Diameter: 560 mm
• Engine: Changchai H16M1, 4‑stroke water‑cooled diesel, 11.5 HP (8.2 kW)
• Travel Speed: 0–6 km/h
• Vibration Frequency: 47 Hz; Centrifugal Force: 35 kN
• Gradeability: 30%
• Fuel Tank Capacity: 12 L

Core Advantages

1. Compact & FlexibleSmall turning radius and lightweight design enable easy operation in narrow areas such as trenches, pipeline ditches, and urban road corners.
2. Full‑Hydraulic Drive & VibrationEquipped with a full‑hydraulic dual‑wheel drive system and single‑drum vibration (front drum). The hydraulic steering and infinitely variable speed ensure smooth and precise control.
3. Reliable Power & DurabilityPowered by a well‑known Changchai diesel engine, it offers strong power, low fuel consumption (≤245 g/kW·h), and long service life. The hydraulic system uses high‑quality components for stable performance.
4. Versatile & Cost‑EffectiveIdeal for compacting asphalt, gravel, sand, and soil. Suitable for road repair, parking lots, sports fields, and garden paths. It provides high efficiency at a low operating cost.

Standard Features

• Scrapers & Water Sprinklers: Front and rear drums fitted with scrapers and electric water sprinklers to prevent material sticking and reduce dust.
• Easy Maintenance: Large opening engine cover for convenient daily checks and servicing.
• Safety Design: Roll‑over protective structure (ROPS) and comfortable seat to enhance operator safety and comfort.
