1. Core Design & Key Features
- Compact & Maneuverable: With a lightweight operating mass of 770 kg and a narrow width of 880 mm, the LTC08H excels in tight spaces. Its small turning radius of 2,700 mm and ±30° steering angle ensure exceptional agility.
- Powerful & Efficient Engine: Powered by a 5.68 kW CF186F vertical direct-injection air-cooled diesel engine, it delivers strong, consistent performance. It features dual starting systems (electric and recoil), guaranteeing reliable starts in all conditions.
- Full Hydraulic Drive: Equipped with imported high-quality hydraulic components (Sauer Danfoss pump, Eaton motor), it offers smooth, infinitely variable speed control (0–4 km/h) and responsive handling.
- All-Wheel Drive: Provides excellent traction and a formidable 40% gradeability, ensuring stable performance on slopes.
Ergonomic Operation: The intuitive handlebar and steering wheel design reduce operator fatigue, making long work sessions comfortable and efficient.
2. Compaction Performance
- Double-Drum Vibratory System: Dual steel drums (width: 600 mm, diameter: 400 mm) provide uniform compaction.
- High Excitation Force: Delivers a centrifugal force of 12 kN at a frequency of 48 Hz and amplitude of 0.25 mm, achieving excellent density for soil, gravel, and asphalt.
- Static Linear Load: 62 N/cm on both front and rear drums for consistent surface quality.
3.ParameterSpecificationOperating Weight770 kgEngine Power5.68 kW (7.6 HP)Travel Speed0–4 km/hVibration Frequency48 HzCentrifugal Force12 kNAmplitude0.25 mmDrum Width600 mmGrade Ability40%Overall Dimensions (L×W×H)2400 × 880 × 1100 mm
4. Applications
The LTC08H is a versatile compaction solution for:
- Municipal Road Maintenance & Repair
- Residential & Commercial Building Site Preparation
- Pipeline & Cable Trench Backfilling
- Asphalt Patching & Repair
- Landscaping & Sports Ground Construction
- Narrow Alleys, Parking Lots, and Small Courtyards
5. Why Choose the LTC08H?
- Small Size, Big Performance: Packs powerful compaction into a highly portable package.
- Durable & Low Maintenance: Rugged construction and reliable components minimize downtime.
- Easy to Operate: User-friendly design requires minimal training.
- Cost-Effective: Ideal for small to medium projects, offering a strong return on investment.
In summary, the LTC08H is a professional, dependable, and highly maneuverable mini-roller that combines power, efficiency, and comfort. It is an indispensable tool for contractors and municipalities needing high-quality compaction in confined spaces.
